Bit Switches - 2
SM 95 D418
Fax Option
Type 9001
D418
Printer Switch 04 (SP No. 1-103-005)
No Function Comments
Maximum reducible length when length reduction is enabled with switch 03-0
above.
[Maximum reducible length] = [Paper length] + (N x 5mm)
"N" is the decimal value of the binary setting of bits 0 to 4.
Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Setting
0 0 0 0 0 0 mm
0 0 0 0 1 5 mm
0 0 1 0 0 20 mm
1 1 1 1 1 155 mm
0
to
4
For A5 sideways and B5 sideways paper
[Maximum reducible length] = [Paper length] + 0.75 x (N x 5mm)
Length of the duplicated image on the next page, when page separation has
taken place.
Bit 6 Bit 5 Setting
0 0 4 mm
0 1 10 mm
1 0 15 mm
5
6
1 1 Not used
7 Not used. Do not change the setting.
Printer Switch 05 - Not used (do not change the settings)
