NCU Parameters
SM 143 D418
Fax Option
Type 9001
D418
Address Function Unit Remarks
frequency upper limit (high byte)
6805A7
Acceptable CNG detection
frequency upper limit (low byte)
FF(H), tone detection is
disabled.
6805A8
Acceptable CNG detection
frequency lower limit (high byte)
6805A9
Acceptable CNG detection
frequency lower limit (low byte)
BCD (Hz)
If both addresses contain
FF(H), tone detection is
disabled.
6805AA Not used
Do not change the
setting.
6805AB CNG on time 20 ms Factory setting: 500 ms
6805AC CNG off time 20 ms Factory setting: 3000 ms
6805AD
Number of CNG cycles required
for detection
The data is coded in the
same way as address
680533.
6805AE Not used
Do not change the
settings.
6805AF
Acceptable AI short protocol
tone (800Hz) detection
frequency upper limit (high byte)
6805B0
Acceptable AI short protocol
tone (800Hz) detection
frequency upper limit (low byte)
Hz (BCD)
If both addresses contain
FF(H), tone detection is
disabled.
6805B1
Acceptable AI short protocol
tone (800Hz) detection
frequency lower limit (high byte)
6805B2
Acceptable AI short protocol
tone (800Hz) detection
frequency lower limit (low byte)
Hz(BCD)
If both addresses contain
FF(H), tone detection is
disabled.
