Replacement and Adjustment
D454 66 SM
Size Setting Default Range
A3 SEF S 0 mm ±10 mm
B4 SEF S 0 mm ±10 mm
A4 SEF S 0 mm ±10 mm
DLT S 0 mm ±10 mm
LG S 0 mm ±10 mm
LT SEF S 0 mm ±10 mm
Other S 0 mm ±10 mm
Pitch Adj. ±1 mm
Notes
No folding adjustment can be done for 13"x19.2", 13"x19", 12.6"x19.2"
Engine SP Adjustment
The following fine adjustment of "S" can be done by the customer engineer in the SP mode.
