Details
D454 130 SM
Sensors
feed. Used to create timing for registration
buckle adjustment during paper feed.
Detects the condition of the stacked
sheets during multi-sheet folding.
S Registration Roller HP Sensor
Detects when registration roller is in and
out of its home position.
S Dynamic Roller HP Sensor
Detects when dynamic roller is in and out
of its home position.
S Fold Plate HP Sensor
Detects when the fold plate is in and out of
its home position.
S Direct-Send JG HP Sensor
Detects when the direct-send junction gate
is in and out of its home position.
S Stopper 2 Paper Sensor
Checks for the presence of paper at power
on. Also checks for jams during paper
feed. Used to create operation timing of
the LE pawl solenoid.
S Stopper 2 HP Sensor
Detects when Stopper 2 is in and out of its
home position.
S Bypass Exit Paper Sensor
Checks for the presence of paper at power
on.
S Bypass Entrance Paper Sensor
Checks for the presence of paper at power
on.
S Stopper 3 Paper Sensor
Checks for the presence of paper at power
on. Also checks for jams during paper
feed. Used to create the timing that
operates the 2nd fold motor during FM6
folding..
S Stopper 3 HP Sensor
Detects when Stopper 3 is in and out of its
home position.
