Duplex Unit
SM 4-81 D062/D063/D065/D066
Replacement
and
Adjustment
2")
Left half of the table
Jogger motor bracket
Slip the one end of the belt around the gear below the jogger motor.
Slip the other end of the belt around the gear at the other side of the duplex
unit.
1. If you are replacing the belt, set both jogger fence brackets at the center of the belt and
tighten the screw [A].
2. If you are adjusting the belt, loosen the screw and slide the plastic piece [B] on the belt
to the left or right to adjust the position of the front fence, then tighten the screw.
To Next Page
