Service Call Conditions
SM Appendix 3-17 D062/D063/D065/D066
Appendix:
Service Call
Conditions
Development output abnormal
D
The high voltage applied to the development unit is detected 10 times
higher than the upper limit (45%) of PWM.
345
-
Development power pack defective
Development bias leak due to poor connection, defective connector
ID sensor error 1
C
One of the following ID sensor output voltages was detected twice
consecutively when checking the ID sensor pattern.
Vsp greater than or equals 2.5V
Vsg less than 2.5
Vsp = 0V
Vsg = 0
350
-
ID sensor defective
ID sensor harness disconnected
ID sensor connector defective
IOB defective
ID sensor pattern not written correctly
Incorrect image density
Charge power pack defective
ID sensor dirty
ID sensor error 2
C
The ID sensor output voltage is 5.0V and the PWM signal input to the ID
sensor is 0 when checking the ID sensor pattern.
351
-
ID sensor defective
ID sensor harness disconnected
ID sensor connector defective
IOB defective
ID sensor pattern not written correctly
Incorrect image density
To Next Page
