Service Call Conditions
D062/D063/D065/D066 3-24 SM Appendix
pushed it in 3 times.
If the operator turns the machine
off/on before the 3rd opening and
closing of the tray, the 3-count is
reset.
LCT feed motor malfunction
507 B
One of the following conditions is
detected:
The LD signal from the feed
motor is detected abnormal
for 50 ms after the motor
switches on.
At power on, the motor is
detected loose or
disconnected.
Feed motor defective
Feed motor connector disconnected
Obstacle interfering with mechanical
movement of motor.
LCT tray malfunction
510 B
One of the following conditions is
detected:
When the bottom plate is
lifted, the upper limit sensor
does not come on for 18 s.
When the bottom plate is
lowered, the lower limit
sensor does not come on for
18 s.
After lift begins, the upper
limit sensor does not switch
on before the pick-up
solenoid switches on.
The paper end sensor
switches on during lift and
Tray lift motor defective or
connector disconnected
Lift sensor defective or
disconnected
Pick-up solenoid defective or
disconnected
Paper end sensor defective
