Service Call Conditions
SM Appendix 3-85 D062/D063/D065/D066
Appendix:
Service Call
Conditions
No. Location Position Code
357 1st Stopper HP SN: Late N6 to N22
358 1st Stopper HP SN: Lag N6 to N22
359 2nd Stopper HP SN: Late N6 to N22
360 2nd Stopper HP SN: Lag N6 to N22
361 3rd Stopper HP SN: Late N6 to N22
362 3rd Stopper HP SN: Lag N6 to N22
363 Skew Correction Jam N6 to N22
364 Folded Paper Path Jam N1 to N5
366 Entrance JG Motor Jam N1 to N5
367 Fold JG Motor Jam N1 to N5
368 1st Stopper Motor Jam N6 to N22
369 2nd Stopper Motor Jam N6 to N22
370 3rd Stopper Motor Jam N6 to N22
371 Dynamic Roller Trans. Motor Jam N6 to N22
372 Registration Roller Release Motor Jam N6 to N22
373 Fold Plate Motor Jam N6 to N22
374 Jogger Fence Motor Jam N6 to N22
375 Positioning Roller Motor Jam N6 to N22
376 Direct-Send JG Motor Jam N6 to N22
377 FM6 Pawl Motor Jam N6 to N22
399 Main Machine Set. Incorrect
N1 to N5
/ N6 to N22
To Next Page
