Service Program Mode Tables
SM Appendix 4-1 D062/D063/D065/D066
Appendix:
Service
Program
Mode Tables
4. APPENDIX: SERVICE PROGRAM MODE
TABLES
4.1 SERVICE PROGRAM MODE TABLES
4.1.1 SERVICE TABLE KEY
Notation What it means
[range/step]
Example: [–9 to +9/0.1 mm]
The default setting can be adjusted in 0.1mm steps in the range
±9.
Italics Comments added for reference.
*
An asterisk marks the SP's that are reset to their factory default
settings after an NVRAM reset.
DFU Denotes "Design or Factory Use". Do not change this value.
Japan Only The feature or item is for Japan only. Do not change this value.
SEF Short Edge Feed
LEF Long Edge Feed
NIA No Information Available (May 2009)
4.1.2 SYSTEM SP TABLES
SP1xxx Feed
1001* Leading Edge Registration
Adjusts the printing leading edge registration using the trimming area pattern
(SP2902-003, No.18).
[–9 to +9/0/0.1mm]
Specification: 3±2mm
To Next Page
