Ricoh Aficio MP 8001 Service Manual

Service Program Mode Tables
D062/D063/D065/D066 4-60 SM Appendix
Displays the result of the SBU connection check.
[0 to 35535 / 0 / 1digit /step]
0: OK, Other: SBU connection check failure
If the SBU connection check fails, SC144 occurs.
4677
Gain Range Adj Value DFU
001 FC:F:R:Factory Setting
003 FC:L:R:Factory Setting
005 BK:F:R:Factory Setting
007 BK:L:R:Factory Setting
4678
Gain Range Adj Value DFU
001 FC:F:G:Factory Setting
003 FC:L:G:Factory Setting
005 BK:F:G:Factory Setting
007 BK:L:G:Factory Setting
4679
Gain Range Adj Value DFU
001 FC:F:B:Factory Setting
003 FC:L:B:Factory Setting
005 BK:F:B:Factory Setting
007 BK:L:B:Factory Setting
4680
Gain Range Adj Value DFU
001 FC:F:RE:Factory Setting
002 FC:F:RO:Factory Setting
