Service Program Mode Tables
D062/D063/D065/D066 4-70 SM Appendix
Adjusts the lower limit threshold for the white level peak range of Blue signal in
the B/W mode.
[0 to 255 / 64 / 1 digit]
Max: BK
004
Adjusts the upper limit threshold for the white level peak range of Blue signal in
the B/W mode.
[0 to 255 / 245 / 1 digit]
4787* White Level Peak Data R
Factory: FC
001
Displays the factory setting data of white level peak data for Red in the full color
mode.
[0 to 255 / - / 1 digit]
Factory: BK
002
Displays the factory setting data of white level peak data for Red in the B/W
mode.
[0 to 255 / - / 1 digit]
4788* White Level Peak Data G
Factory: FC
001
Displays the factory setting data of white level peak data for Green in the full
color mode.
[0 to 255 / - / 1 digit]
Factory: BK
002
Displays the factory setting data of white level peak data for Green in the B/W
mode.
[0 to 255 / - / 1 digit]
