Service Program Mode Tables
D062/D063/D065/D066 4-114 SM Appendix
1: The Embedded RCG Gate is being set. Only Box registration is completed.
In this status, @Remote device cannot communicate with this device.
2: The Embedded RCG Gate is set. In this status, the @Remote device
cannot communicate with this device.
3: The @Remote device is being set. In this status the Embedded RCG Gate
cannot be set.
4: The @Remote module has not started.
202 Letter Number
Allows entry of the request number needed for the
Embedded RCG Gate.
203 Confirm Execute
Executes the confirmation request to the @Remote
Gateway.
204 Confirm Result
Displays a number that indicates the result of the confirmation executed with
SP5816-203.
0: Succeeded
1: Confirmation number error
2: Registration in progress
3: Proxy error (proxy enabled)
4: Proxy error (proxy disabled)
5: Proxy error (Illegal user name or password)
6: Communication error
7: Certification update error
8: Other error
9: Confirmation executing
Confirm Place
205
Displays the result of the notification sent to the device from the Gateway in
answer to the confirmation request. Displayed only when the result is
registered at the Gateway.
206 Register Execute Executes "Embedded RCG Registration".
Register Result
207
Displays a number that indicates the registration result.
