Service Program Mode Tables
D062/D063/D065/D066 4-128 SM Appendix
11g CTS to Self
043
Determines whether the CTS self function is turned on or off.
[0 to 1 / 1 / 1] 0: Off, 1: On
This SP is displayed only when the IEEE802.11 card is installed.
044 11g Start Time
Selects the slot time for IEEE802.11.
[0 to 1 / 0 / 1] 0: 20 mm, 1: 9 mm
WPA Debug Lvl1
045
Selects the debug level for WPA authentication application.
[1 to 3 / 3 / 1] 1: Info, 2: warning, 3: error
This SP is displayed only when the IEEE802.11 card is installed.
Supply Name Setting
5841
Press the [User Tools] key. These names appear when the user presses the
Inquiry button on the User Tools screen.
001 Toner Name Setting: Black
008 Paste Name
011 Staple Std 1
012 Staple Std 2
013 Staple Std 3
014 Staple Std 4
021 Staple Bind 1
022 Staple Bind 2
023 Staple Bind 3
031 Ring Name (50/black)
032 Ring Name (50/white)
