Ricoh Aficio MP 8001 Service Manual

3000-Sheet Finisher (D460)
SM 2-45 D062/D063/D065/D066
Installation
5. Install the grounding plate [A] (
x 2) (M3 x 6).
 Set the grounding plate so that there is no gap between the grounding plate
and the bottom frame of the finisher (as shown).
6. Install the table extension [A] as shown (
x 2) (M4 x 8).
 The edge of the table extension should be aligned with the edge of the finisher
(as shown).

Ricoh Aficio MP 8001 Specifications

General

Brand	Ricoh
Model	Aficio MP 8001
Category	All in One Printer
Language	English
