SERVICE PROGRAM MODE 1 March, 2000
4-50
6. System Adjustment
SP No. Display Function Default Settings
6-001-1
Main Scan Pos. -
Platen
Side-to-side registration
adjustment; see Note 1.
0 -5.0 to 5.0 mm
6-001-2
Main Scan Position -
DF
0 -5.0 to 5.0 mm
6-002-1
Scan Start Pos. -
Platen
Scanning start line
adjustment; see Note 2.
0 -5.0 to 5.0 mm
6-002-2
Scan Start Position -
DF
0 -5.0 to 5.0 mm
6-010 Master Writing Speed See Note 3. 0 -5.0 to 5.0%
6-011-1
Scanning Speed -
Platen
See Note 4.
0 -5.0 to 5.0%
6-011-2
Scanning Speed - DF
0 -5.0 to 5.0%
6-012 Master Writing Length Do not use in the field. 0 -5.0 to 5.0 %
6-020-1
V&Thresh Master
Eject SN
2.5 0.0 to 5.0V
6-020-2
V&Thresh
DrumMaster 1 SN
2.5 0.0 to 5.0V
6-020-3
V&Thresh
DrumMaster 2 SN
The use of these SP
modes is explained in
various parts of the
Replacement and
Adjustment section. (C229
service manual)
2.5 0.0 to 5.0V
6-020-4
V & Thresh Master
End SN
0.9 0.0 to 5.0V
6-020-5
V & Thresh Paper
Exit SN
2.5 0.0 to 5.0V
6-020-6
V&Thresh Master
Edge SN
1.5 0.0 to 5.0V
6-032-1
SBU Auto Calibration
Refer to the
Replacements and
Adjustments section.
(C229 service manual)
--
6-032-2
SBU Gain Setting
Do not adjust. - -
6-032-3
SBU DC Count
Setting
--
6-032-4
SBU Reference Value
--
6-032-5
SBU Offset Value
--
6-050
LCD Contrast
Adjustment
See Note 5.
6 0 to 7
6-070
Master Making
Density
See Note 6.
1 0 to 2
6-082-1
MTF Filter Letter
Mode
See Note 7.
0 0 to 11
6-082-2
MTF Filter Ltr/Pht
Mode
5 0 to 11
6-082-3
MTF Filter Pencil
Mode
6 0 to 11
6-082-4
MTF Filter Photo
Mode
2 0 to 11
