1 March, 2000 MAINTENANCE TABLE
5-1
Preventive
Maintenance
5. PREVENTIVE MAINTENANCE
5.1 MAINTENANCE TABLE
The following items should be maintained periodically. There are two sets of
intervals - one based on time and the other based on print count. For maintenance
items with entries in both of them, use whichever comes first.
C: Clean, R: Replace, L: Lubricate, A: Adjust
Time Print CounterInterval
Item
6M 1Y 2Y 3Y
300K 600K
1M 1.2M 2M
EM NOTE
Scanner/Optics
Exposure Lamp C C C C Dry Cloth
Mirror/Reflector C C C C Soft Cloth
Scanner Guide Rail C C C C Dry Cloth
Platen Cover /
White Plate
CCCC Damp
Cloth
Exposure Glass C C C C Dry Cloth
Master Feed
Thermal Head C Alcohol
Platen Roller C C C R
Expected
life is 6K
masters.
Master Eject
Rollers
C C C C Alcohol
Master Eject Box C C C C Alcohol
1st and 2nd Drum
Master Sensors
C Dry Cloth
Paper Table
Paper Pick-up
Roller
CCRC R Damp
Cloth
Paper Feed Roller C C R C R
Damp
Cloth
Paper Feed and
Pick-up Roller One-
way Clutches
RR
Friction Pad C C R C R Damp
Cloth
Feed Roller and
Transport Belt
Roller Bushings
L L L Motor Oil
(SAE #20)
Feed Drive Gears L L L Grease
(Alvania
#2)
Paper Delivery
Transport Belts
RR
Paper End Sensor C C C C Dry Cloth
To Next Page
