Ricoh JP5800 - Paper Feed Length Adjustment

PAPER FEED SECTION (MAIN BODY) 1 March, 2000
6-20
6.3.3 PAPER FEED LENGTH ADJUSTMENT
CAUTION:
The last digits of the SP numbers for this adjustment are different from
the C229 model. Please refer to the chart below and note the changes
in the numbers.
C229: Pearl C232: Ruby
SP No. Display Default SP No. Display Default
6-116-1
Paper Clamp Timing
Pulse
143 6-116-1
Paper Clamp Timing
Pulse
145
6-116-2 Regist Timing Pulse 113 6-116-2 Paper Clamp - Thick
Paper
148
6-116-3
Feed Stop Timing
Pulse
25 6-116-3
Paper Clamp Pls -
A4 Cam
145
6-116-4 Regist Speed Ctl
Pulse
20 6-116-4 Regist Timing Pulse 113
6-116-5 Paper Clamp – Thick
Paper
150 6-116-5 Feed Stop Timing
Pulse
21
6-116-6 Regist – Thick Paper 213 6-116-6
Print Position 2
Setting
103
6-116-7 Paper Clamp Pls –
A4 Cam
143 6-116-7 Print Position 1
Setting
140
