DRIVE LAYOUT 1 March, 2000
1-28
1.9 DRIVE LAYOUT
1.9.1 OVERVIEW
1. Clamper Opening Arm Sector
Gear (for the master eject position)
2. Master Pick-up Roller Sector Gear
3. Master Eject Motor
4. Image Shift Motor
5. Pressure Plate Motor
6. Exit Pawl Drive Cam Gear
7. Paper Delivery Unit Drive
Gear/Pulley
8. Main Motor
9. Pressure Cylinder Drive Gear
(Including the Scissors Gear)
10. Registration Roller Lifting Cam Drive
Gear
11. Registration Motor
12. Paper Feed Motor
13. Paper Table Motor
14. Clamper Motor
15. Drum Guide
16. Master Feed Motor
17. Master Feed Clutch
C232V509.WMF
2
1
17
16
15
14
12
11
10
9
8
7
6
5
4
3
13
