DIP SW, LED, VR, TP, AND FUSE TABLES 1 March, 2000
4-2
Service
Tables
4.1.4 LED'S
MPU
Number Function
LED101 Monitors the CPU operation. Usually, this LED is blinking.
LED102 Monitors power supplied to the MPU. Usually, this LED is lit.
I/O Board
Number Function
LED300 Not used.
LED301 Not used.
LED302 Monitors the Master Eject Sensor.
LED303 Monitors the Master Edge Sensor.
LED304 Monitors the feed control CPU operation. Usually, this LED is blinking.
LED305 Monitors power supplied to the I/O board. Usually, this LED is lit.
4.1.5 FUSES
Power Supply Unit
Fuse Rated Current Protect
FU700 10A Power Supply Unit
FU701 5A Main Motor Drive Board
FU702 5A Main Motor Drive Board
FU703 5A I/O Board
FU704 5A Thermal Head Power Supply Board, I/O Board
FU706 2A Power Supply Unit
Thermal Head Power Supply Board
Fuse Rated Current Protect
FU750 2A Thermal Head
Main Motor Control Board
Fuse Rated Current Protect
FUSE 10A Main Motor
To Next Page
