Ricoh JP5800 - 4 Service Tables; Dip Sw, Led, Vr, Tp, and Fuse Tables; Test Points; Dip Switches

1 March, 2000 DIP SW, LED, VR, TP, AND FUSE TABLES
4-1
Service
Tables
4. SERVICE TABLES
4.1 DIP SW, LED, VR, TP, AND FUSE TABLES
4.1.1 TEST POINTS
Ink Detection Board
Number Usage
TP1 Ink Level
TP2 Ink Level
TP-12V -12V
4.1.2 DIP SWITCHES
Ink Detection Board
Number
Standard A3
Drum
Optional A3
Drum
Optional A4
Drum
Not used
DPS901-1 ON OFF ON OFF
DPS901-2 ON ON OFF OFF
4.1.3 POTENTIOMETERS
I/O Board
Number Usage
VR303 Master Eject Sensor Adjustment
VR304 Master End Sensor Adjustment (Do not adjust.)
VR305 1st Drum Master Sensor Adjustment
VR306 2nd Drum Master Sensor Adjustment
VR307 Master Edge Sensor Adjustment
Thermal Head Power Supply Board
Number Usage
VR1 Thermal Head Voltage Adjustment
Ink Detection Board
Number Usage
VR901 Ink Detection Board Adjustment
