Ricoh JP5800 - Page 120

1 March, 2000 SERVICE PROGRAM MODE
4-53
Service
Tables
SP No. Display Function Default Settings
6-113-1
Thick Regist Delay -
16
43 0 to 255
6-113-2
Regist Delay - 20 rpm
43 0 to 255
6-113-3
Regist Delay - 30 rpm
43 0 to 255
6-113-4
Regist Delay - 60 rpm
40 0 to 255
6-113-5
Regist Delay - 75 rpm
Do not adjust. (Changes
the registration motor on
timing in thick and special
paper modes after the
feed start timing sensor is
activated.)
35 0 to 255
6-113-6
Regist Delay - 90 rpm
30 0 to 255
6-113-7
Regist Delay - 105
rpm
25 0 to 255
6-113-8
Regist Delay - 120
rpm
20 0 to 255
6-114-1
A4 Regist Delay - 16
rpm
33 0 to 255
6-114-2
Regist Delay - 20 rpm
33 0 to 255
6-114-3
Regist Delay - 30 rpm
33 0 to 255
6-114-4
Regist Delay - 60 rpm
30 0 to 255
6-114-5
Regist Delay - 75 rpm
Do not adjust. (Changes
the registration motor on
timing in the use of the A4
drum after the feed start
timing sensor is
activated.)
28 0 to 255
6-114-6
Regist Delay - 90 rpm
24 0 to 255
6-114-7
Regist Delay - 105
rpm
19 0 to 255
6-114-8
Regist Delay - 120
rpm
13 0 to 255
6-115-1
A4 Thick Regist
Delay 16
43 0 to 255
6-115-2
Regist Delay - 20 rpm
43 0 to 255
6-115-3
Regist Delay - 30 rpm
43 0 to 255
6-115-4
Regist Delay - 60 rpm
40 0 to 255
6-115-5
Regist Delay - 75 rpm
35 0 to 255
6-115-6
Regist Delay - 90 rpm
30 0 to 255
6-115-7
Regist Delay - 105
rpm
Do not adjust. (Changes
the registration motor on
timing in thick and special
paper modes in
combination with the use
of the A4 drum after the
feed start timing sensor is
activated.)
25 0 to 255
6-115-8
Regist Delay - 120
rpm
20 0 to 255
6-116-1
Paper Clamp Timing
Pulse
See Replacements and
Adjustments – Paper
Feed Length Adjustment
for how to use.
145 0 to 255
6-116-2
Paper Clamp - Thick
Paper
See Replacements and
Adjustments – Paper
Feed Length Adjustment
for how to use.
148 0 to 255
6-116-3
Paper Clamp Pls - A4
Cam
Do not adjust. 145 0 to 255
6-116-4
Feed Timing Pulse
Do not adjust. 113 0 to 255
6-116-5
Feed Stop Timing
Pulse
See Replacements and
Adjustments – Paper
Feed Length Adjustment
for how to use.
21 0 to 255
