1 March, 2000 SERVICE PROGRAM MODE
4-63
Service
Tables
8. System Test
SP No. Display (Comments)
8-010-1 Scanner Free Run M
8-010-2 Magnification at FreeRun
8-011-1 ADF Free Run Mode
8-011-2 Mag. at ADF Free Run
8-020 Load Program (See "4.5.4 Load Program" section.)
8-020-1 Load Program
8-020-2 Load Program-ProgramData (factory use only)
8-020-3 Load Program-Font Data (factory use only)
8-020-4 Load Program-ExceptUStamp (factory use only)
8-021 UpLoad Program
8-030 APS Sensor Check Mode
8-040 TH Test Pattern Select (Patterns 0 to 9, 0: No pattern)
8-050-1 Make Master with Pattern
8-050-2 Make-up Pattern Number
8-070-1 Logging Data Printout (Needs the optional memory board)
8-070-2 User Code Counters Only (Needs the optional memory board)
8-070-3 Jam & SC Counters Only (Needs the optional memory board)
8-070-4 Jams/Errors Details (Needs the optional memory board)
8-071 Basic Settings Printout (Needs the optional memory board)
8-072-1
UserCustomSettings Print, excludes class mode (Needs the optional
memory board)
8-072-2 Class Mode Settings (Needs the optional memory board)
8-073-1 Input Test Item Printout (Needs the optional memory board)
8-073-2 OutputTest Item Printout (Needs the optional memory board)
8-074-1 System Adjustment Print (Needs the optional memory board)
8-074-2 Paper Feed Adjustments (prints a list of SP values from 6-90 to 6-118)
8-074-3 Option Adjustment Print (prints a list of SP values from 6-140 to 6-151, and
6-660 to 6-662)
8-080 Not used
8-100-1
Register User Stamp A (UP Mode 5-8)
8-100-2
Register User Stamp B (UP Mode 5-8)
8-100-3
Register User Stamp C (UP Mode 5-8)
8-100-4
Register User Stamp D (UP Mode 5-8)
8-110
Register Makeup Pattern (UP Mode 5-15)
