Replacement
Adjustment
CAUTION:
Make sure that the distance between the feed encoder sensor [A] and
the sensor bracket is less than 0.2 mm.
B: Paper table feed start sensor
C: Paper tray feed start sensor
C232R015.WMF
[A]
[B]
[C]
0.2 mm
