A Web browser opens and the dialog box for entering the login user name and password for the
Web Image Monitor administrator appears.
NIB Setup Tool starts when the network interface board is default. Follow the instructions on the screen.
5. Enter the login user name and password, and then click [Login].
For details about the user name and password, consult your network administrator.
6. Click [Configuration].
7. Click [Program/Change Administrator] on the [Device Settings] area, and then change the
settings.
8. Click [Logout].
9. Quit Web Image Monitor.
10. Quit SmartDeviceMonitor for Admin.
• For details about login user names and passwords, see Security Reference, which is the administrator's
manual.
Checking the Machine Status
Follow the procedure below to check machine status.
1. Start SmartDeviceMonitor for Admin.
2. On the [Group] menu, point to [Search Device], and then click [IPv4], [IPX/SPX] or [IPv4
SNMPv3].
A list of machines using the selected protocol appears.
Select the protocol of the machine whose configuration you want to change.
If you are using TCP/IP SNMP v3, enter the user authentication.
3. Click the [View] menu, and then click [Select List Columns].
4. From [Device] in the [Select List Columns] dialog box, select the items you want to display,
and then click [Add].
Selected items will move to [Show].
5. Move all the items you want to display, and then click [OK].
An icon in the list indicates the machine's status.
6. For information about a machine's status, select the machine you want to know about, and
then click [Open] in the [Device Settings] menu.
The dialog box of the selected machine appears.
7. Click the application whose status you want to view.
The machine's status is displayed.
Using SmartDeviceMonitor for Admin
47
