Broadcast address configuration
msh> ifconfig “interface_name” broadcast “address”
Changing the interface
msh> ifconfig “interface” up
When using the optional IEEE 802.11 interface unit, you can specify either Ethernet or IEEE
802.11 interface.
To get the above addresses, contact your network administrator.
Use the default configuration if you cannot obtain setting addresses.
The IP address, subnet mask and broadcast address are the same as that for the ethernet interface
and IEEE 802.11 interface.
TCP/IP configuration is the same for both Ethernet and IEEE 802.11 interface. If interfaces are
changed, the new interface inherits the configuration.
Use “0x” as the initial two letters of a hexadecimal address.
info
Use the “info” command to display printer information such as paper tray, output tray, and printer language.
Printer information display
msh> info
p.112 "Understanding the Displayed Information"
ipp
Use the “ipp” command to view and configure IPP settings.
Viewing settings
The following command displays the current IPP settings:
msh> ipp
IPP timeout configuration
Specify how many seconds the computer waits before canceling an interrupted print job. The time
can be entered between 30 to 65535 seconds.
msh> ipp timeout [30-65535]
2. Monitoring and Configuring the Printer
74
2
