Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
[2 Holes Type JP / EU] 0.0 2.0 -2.0 0.4 mm
[3 Holes Type US]
[4 Holes Type EU]
[4 Holes Type NE]
[2 Holes Type US]
[1 Hole Type JP]
0402: [Punch Position: Across Feed]
Adjust the vertical position of the punch holes when using Finisher SR4120 or Finisher SR4130.
Press [+] to move the position forward (up), or [−] to move it backward (down).
Paper feed direction
Paper feed direction
2 Holes Top
2 Holes Left
CDS027
Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
[2 Holes Type JP / EU] 0.0 2.0 -2.0 0.5 mm
[3 Holes Type US]
[4 Holes Type EU]
[4 Holes Type NE]
[2 Holes Type US]
[1 Hole Type JP]
2. Details of Menu Items in Adjustment Settings for Skilled Operators
