If the paper feed roller fails to pick up slippery paper such as coated paper, and misfeeding of paper
occurs, set this to [On].
Setting Items Values Default Value
[Wide LCT] [Auto Select]
[On]
[Off]
[Auto Select]
• This setting is not effective for paper fed from paper trays with custom paper presets. For such
paper, the value specified in [Pickup Assist Setting] in [Advanced Settings] takes precedence.
[Finishing: Finisher]
0401: [Punch Position: With Feed]
Adjust the horizontal position of the punch holes when using Finisher SR4120 or Finisher SR4130.
Press [+] to move the position toward the top edge (left) relative to the paper feed direction, or [−] to
move it toward the bottom edge (right).
Paper feed direction
Paper feed direction
2 Holes Top
2 Holes Left
CDS026
Setting Values
47
