Ricoh Pro C5200s Operating Instructions

Setting Items Max. Value Min. Value Step Unit
[Textured Paper Mode Voltage: FC: Side
1]
14.0 0.0 0.1 KV
036: [Textured Paper Mode Voltage: FC: Side 2]
Adjust the paper transfer voltage applied to Side 1 when printing in full color with Textured Paper mode
enabled.
Press [+] to increase the voltage and [−] to reduce it.
Setting Items Max. Value Min. Value Step Unit
[Textured Paper Mode Voltage: FC: Side
2]
14.0 0.0 0.1 KV
Fuser Adjustment
050: [Fusing Temp]
Adjust the heat roller temperature.
Press [+] to increase the temperature and [−] to reduce it.
• Decreasing the temperature too much may cause the toner to not properly fuse to the paper (cold
offset).
• Increasing the temperature too much may distort the paper and cause glossy lines, paper jams,
and insufficient toner fusing (hot offset).
• Depending on the type of paper, you can increase the toner gloss by increasing the temperature
by 5 to 10°C over the initial factory setting.
Setting Items Max. Value Min. Value Step Unit
[Fusing Temp] 200 100 1 degree(s)
051: [Fusing Pressure Roller Temp]
Adjust the pressure roller temperature.
Press [+] to increase the temperature and [−] to reduce it.
Setting Values
141

Ricoh Pro C5200s Specifications

General

Print Technology	Laser
Max Paper Size	330.2 x 487.7 mm
Monthly Duty Cycle	300, 000 pages
Print Speed	65 ppm
Resolution	1200 x 4800 dpi
Paper Input Capacity	8, 250 sheets
Paper Weight	52 to 360 gsm
Duplex Printing	Standard
Network Connectivity	Ethernet 10Base-T/100Base-TX/1000Base-T
Supported Media Sizes	A3, A4, A5, B4, B5
Supported Media Types	Plain, Recycled, Coated, Envelope
Warm-up Time	Less than 5 minutes
