2.Replacement and Adjustment
60
Boards
Controller Board (PCB1)
1. Remove the following covers.
• Rear upper cover (Rear Upper Cover, Rear Lower Cover)
• Rear lower cover (Rear Upper Cover, Rear Lower Cover)
2. Remove the Controller Board (PCB1) [A].
Booklet Finisher SR3290
Finisher SR3280
