2.Replacement and Adjustment
50
2. Replacement and Adjustment
Covers
Rear Upper Cover, Rear Lower Cover
1. Remove the Rear upper cover [A].
2. Remove the Rear lower cover [A].
Upper Cover
1. Remove the rear upper cover. (Rear Upper Cover, Rear Lower Cover)
