2.Replace
ment and
Adjustment
90
Paper Guide Motor (STM18)
The Paper
Guide Motor
(STM18) is at
[A].
1.
Remove
the paper guid
e unit. (
Paper
Guide Unit
)
2.
Remove
sensor brac
ket (
x1).
3.
Unfasten t
he motor
, and disconnect
the belt (
x2,
x1).
95
97
