Ricoh SR3290 - Press Fold Motor (STM10)

2.Replacement and Adjustment
80
4. Remove the screws securing the finisher and saddle stitch unit.
5. Lift up to remove the saddle stitch unit [A].
Press Fold Motor (STM10)
1. Remove the saddle stitch unit (Saddle Stitch Unit).
