Ridder FertiMiX-Go! - Filling Module with Float Valve

No. Description No. Description
7 Connection point for fresh
water supply
15 Venturi (at least 1, no more than 5)
8 Connection point for
irrigation water
distribution
16 Supply pipe(s) (at least 1, no more than 5)
for fertilizers and acid/alkali (optional)
The following table provides an overview of the main specifications of the FertiMiX-
Go! basic configuration(s):
Component Specifications
Nominal capacity at 4 bars 10 [m
3
/h]
Dimensions (W x H x D) 116 x 102 x 66 [cm]
Dimensions of basic cabinet (W x H x D) 60 x 40 x 20 [cm]
Mixing tank volume 100 [l]
Electrical voltages and frequencies 3 x 400 [V], 50 [Hz], with neutral and
earth
3 x 400 [V], 60 [Hz], with neutral and
earth
3 x 230 [V], 50 [Hz], with earth
3 x 230 [V], 60 [Hz], with earth
Process controller HortiMaX-Go!
User interface on the FertiMiX
(standalone)
Yes
2.3.2 Filling module with float valve
The filling module is located directly after the connection point of the fresh water
supply.
The float valve shuts off the water supply if the water level in the mixing tank rises
too high. You can also use the button on the float valve to control the water supply to
the mixing tank manually.
FertiMiX
12
