2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-301
:TRIGger:RUNT:WHEN
Syntax
:TRIGger:RUNT:WHEN <when>
:TRIGger:RUNT:WHEN?
Description
Set or query the qualifier of runt trigger.
Parameter
Name Type Range Default
<when> Discrete {NONE|GREater|LESS|GLESs} NONE
Explanation
 NONE: do not set the trigger condition of runt trigger.
 GREater (>):trigger when the runt pulse width is greater than the lower limit of pulse width (refer to
the
:TRIGger:RUNT:WLOWer command).
 LESS (<):trigger when the runt pulse width is lower than the upper limit of pulse width (refer to
the
:TRIGger:RUNT:WUPPer command).
 GLESs (<>):trigger when the runt pulse width is greater than the lower limit (refer to
the
:TRIGger:RUNT:WLOWer command) and lower than the upper limit (refer to
the
:TRIGger:RUNT:WUPPer command) of pulse width.
Note: The lower limit of the pulse width must be lower than the upper limit.
Return Format
The query returns NONE, GRE, LESS or GLES.
:TRIGger:RUNT:WLOWer
Syntax
:TRIGger:RUNT:WLOWer <NR3>
:TRIGger:RUNT:WLOWer?
Description
Set or query the lower limit of the pulse width in runt trigger.
Parameter
Name Type Range Default
<NR3> Discrete
When the qualifier is >: 2ns to 4s
When the qualifier is <>: 2ns to 3.99s
1us
Return Format
The query returns the lower limit of the pulse width in scientific notation.
