Rigol 2000 Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-313
:TRIGger:SPI:DATA
Syntax
:TRIGger:SPI:DATA <data>
:TRIGger:SPI:DATA?
Description
Set or query the data value in SPI trigger.
Parameter
Name Type Range Default
<data> Integer 0 to 2
n
-1 0
Note: In the expression 2
n
-1, n is the current data bits (refer to the :TRIGger:SPI:WIDTh command).
Return Format
The query returns an integer.
:TRIGger:SPI:SCL
:TRIGger:SPI:SDA
Syntax
:TRIGger:SPI:SCL <scl>
:TRIGger:SPI:SCL?
:TRIGger:SPI:SDA <sda>
:TRIGger:SPI:SDA?
Description
Set or query the SCL or SDA channel source in SPI trigger.
Parameter
Name Type Range Default
<scl> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel1
<sda> Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|
D11|D12|D13|D14|D15|CHANnel1|CHANnel2}
CHANnel2
Return Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14, D15, CHAN1 or
CHAN2.
