Rigol 2000 Series Programming Guide

2 Command System RIGOL
MSO2000A/DS2000A Programming Guide
2-79
:CURSor:MANual:CAY
:CURSor:MANual:CBY
Syntax
:CURSor:MANual:CAY <ay>
:CURSor:MANual:CAY?
:CURSor:MANual:CBY <by>
:CURSor:MANual:CBY?
Description
Set or query the vertical position of cursor A or cursor B in manual cursor measurement.
Parameter
Name Type Range Default
<ay> Integer 0 to 399 100
<by> Integer 0 to 399 300
Explanation
 The horizontal and vertical positions of the cursor are defined by the pixel coordinate of the screen.
The pixel coordinate of the screen ranges from (0,0) to (700,400). Wherein, (0,0) is located at the
left top corner of the screen and (700,400) is located at the right bottom corner of the screen. The
horizontal pixel range is from 0 to 699 and the vertical pixel range is from 0 to 399.
 When the measurement source is LA (
:CURSor:MANual:SOURce), this command is invalid.
Return Format
The query returns an integer between 0 and 399.
