RIGOL Chapter 13 Specifications
User’s Guide for DG5000
13-8
Maximum Rate 1MHz
Clock Reference
Phase Offset
Range 0° to 360°
Resolution 0.001° (arb waveform), 0.03° (other waveforms)
External Reference Input
Lock Range 10 MHz ± 50 Hz
Level 80 mVpp to 10 Vpp
Lock Time < 2 s
Internal Reference Output
Frequency 10 MHz ± 50 Hz
Level 632 mVpp (0 dBm), nominal value
Sync Output
Level TTL-compatible
Impedance 50 Ω, nominal value
General Specifications
Power
Power Voltage 100-127 V, 45-440Hz
100-240 V, 45-65Hz
Power
Consumption
Less than 125 W
Fuse 250V, T3A
Display
Type 4.3-inch TFT LCD
Resolution 480 Horizontal × RGB × 272 Vertical Resolution
Color 16M color
Environment
Temperature
Range
Operating: 10℃ to 40℃
Non-Operating: -20℃ to 60℃
Cooling Method Cooling by fans compulsively
Humidity
Range
Less than 35℃: ≤90％ Relative Humidity (RH)
35℃ to 40℃: ≤60％ Relative Humidity (RH)
Altitude Operating: Less than 3000 meters
Non-Operating: Less than 15000 meters
