TIP
By default, XY mode is unavailable. It is available only when the horizontal time base mode is
"XY". To enable the XY mode, please refer to Enable the XY Mode .
Adjust Cursor Position
• Click or tap to select the "X" tab under the Select menu item to set the X value
for the specified cursor.
- Click or tap the input field of AX and use the pop-up numeric keypad to set
the X value at Cursor A.
- Click or tap the input field of BX and use the pop-up numeric keypad to set
the X value at Cursor B.
- Click or tap the AX BX on/off switch to turn on/off adjusting the X value at
Cursor A and the X value at Cursor B simultaneously.
• Click or tap to select "Y" under the Select item to set the Y value for the
specified cursor.
- Click or tap the input field of
AY and use the pop-up numeric keypad to set
the Y value at Cursor A.
- Click or tap the input field of BY and use the pop-up numeric keypad to set
the Y value at Cursor B.
- Click or tap to the
AY BY on/off switch to turn on/off adjusting the Y value
at Cursor A and the Y value at Cursor B simultaneously.
You can also use the front-panel multipurpose knob
to adjust the cursor
position. To configure the multipurpose knobs, please refer to Front Panel Overview .
During the adjustment, the measurement results will change accordingly. The
adjustable range is limited within the screen.
Disable the Cursor Measurement Function
When cursor measurement is enabled, you can disable it in the following ways:
• In the
Cursors menu, click or tap the Remove button to disable cursor
measurements.
• In the "Result" bar at the right side of the screen, click or tap the "Cursors" label
and then click or tap
Remove in the pop-up window.
• In the "Result" bar at the right side of the screen, drag the "Cursors" label to the
right to simply disable cursor measurements.
• Press the front-panel
key to disable cursor measurements.
