To Next Page

To Previous Page

Security Lock Hole

Figure 4.20 To Use the Security Lock

CAUTION

Please do not insert other objects into the security lock hole to avoid damaging the

instrument.

4.8 To Use the Built-in Help System

The built-in help file provides information about the functions and menu

introductions of the instrument. Click or tap > Help to enter the help system.

In the help system, you can get its help information by clicking on or tapping the link

for the specified chapter.
