21
Search and Navigation
The Search function allows you to quickly find and mark the event of interest and
then go to the specified event in the marktable by navigating search events. The
search types include edge and pulse.
The Navigation function allows you to navigate time, search events, and segments.
21.1 Search
This function allows you to search for the specified edge and pulse width trigger
vents. Found search events are marked with small inverted triangles ( ) at the top
of the graticule. Click or tap > Search to enter the "Search" menu. You can also
click or tap Search in the "Navigation" menu (only when the navigation mode is set to
"Search Event") to enter the "Search" menu, as shown in the figure below.
Figure 21.1 Search Menu
1.
Search On/Off
Click or tap
Search on/off switch to enable or disable the search function.
TIP
Enabling the search function automatically turns on the
Zoom Mode (Delayed Sweep)
.
2. Set up searches
Search and Navigation
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO900 User Guide
225
