• Tap the close button at the upper-right corner of the message box to close the

prompt window.

• Tap other windows on the touch screen and operate on the windows.

Figure 4.13 Tap Gesture

4.5.2 Drag

Use one finger to select the object, and then drag the object to a destination place, as

shown in the figure below. With the drag gesture, you can perform the following

operation:

• Drag the waveform to change its position or scale.

• Drag the window controls to change the position of the window (e.g. numeric

keypad).

• Drag the cursor to move the cursor.

• Drag the trigger cursor to change the trigger level.

• In multi-window display, drag one of the displayed windows to change its

position on the display.

Figure 4.14 Drag Gesture
