To Next Page

To Previous Page

Parameter Factory Settings

Source CH1

Scale 500 mU

Offset 0 U

Abs

Operation OFF

Source CH1

Scale 500 mV

Offset 0 V

Low Pass

Operation OFF

Source CH1

Scale 500 mV

Offset 0 V

ωc 20 MHz

High Pass

Operation OFF

Source CH1

Scale 500 mV

Offset 0 V

ωc 20 MHz

Band Pass

Operation OFF

Source CH1

Scale 500 mV

Offset 0 V

ωc1 20 MHz

ωc2 40 MHz

Band Stop

Operation OFF

Source CH1

Scale 500 mV

Offset 0 V

ωc1 20 MHz

ωc2 40 MHz

AX+B

Operation OFF

Source CH1

Scale 500 mV

Offset 0 V

A 1

B 0
