Parameter Factory Settings

MISO CH2

MISO Threshold 0 V

MOSI OFF

Mode CS

CS CH3

CS Threshold 0 V

CS Polarity Negative

Polarity Positive

Width 8

Endian MSB

LIN

Source CH1

Threshold 0 V

Baud Rate 9.6 kbps

Parity Without

Version Both

CAN

Source CH1

Threshold 0 V

Signal Type CAN_H

Baud 1 Mbps

Sample Position 50%

D0-D7 OFF

D8-D15 OFF

D0-D7 Threshold 0 V

D8-D15 Threshold 0 V

Waveform Size Medium

Auto D15-D0

Enable ON

Function/Arbitrary Waveform Generator (only for DHO914S and DHO924S)

Output On/Off OFF

Waveform Type Sine

Frequency 1 kHz

Amplitude 5 V

Offset 0 V

Phase 0°

Bode Plot (only for DHO914S and DHO924S)

Bode Plot OFF

Appendix

271
