4. USB DEVICE

Connect the instrument to the PC via this interface. Then you can use the PC

software to send the SCPI commands or use the user-defined programming to

control the instrument.

5. HDMI

You can connect the instrument to an external display that has the HDMI interface

(e.g. monitor or projector) via this interface to better observe the waveform display

clearly. At this time, you can also view the waveforms on the LCD of the

instrument.

6. USB Type-C Power Connector

The power requirements of the oscilloscope are DC, 12 V, 4 A. Please use the

power adaptor provided in the accessories to connect the oscilloscope to the AC

power source (100 V to 240 V, 50 Hz to 60 Hz).

7. Security Lock Hole

Use a standard PC/laptop lock cable to secure the oscilloscope to a work bench or

other location.

8. Ground Terminal

Connect the instrument chassis to the ground using the lead.

9. Mounting Screws

Interval of screw holes: 100 mm x 100 mm. Use screws to secure the oscilloscope

to the bracket with the same screw hole interval.

Quick Start
