RIGOL Chapter 6 Operations and Measurements
6-26 MSO5000 User Guide
⚫ Press More → Label to set the label for math operation results. For details,
refer to descriptions in "Math Operation Label".
⚫ Press More → Color Grade to enable or disable the color grade display of the
operation results. When enabled, different colors are displayed on the screen to
indicate the times of data acquisition or acquisition probability.
⚫ Press More → Reset ColorGrade to clear the color grade display and display
the color grade again.
Math Operation Label
Press Label to enter the label setting menu.
⚫ Press Display Label continuously to enable or disable the label display of the
waveform. If it is enabled, the label will be displayed at the left side of the
waveform.
⚫ Press Library to select the preset waveform label, including ADD, SUB, MUL,
DIV, FFT, AND, OR, XOR, NOT, Intg, Diff, Sqrt, Lg, Ln, Exp, Abs, LPas, HPas, BPas,
Bstop, and AX+B.
⚫ Press Label, and the label editing interface is automatically displayed. You can
input the label manually. For details, refer to descriptions in "Channel Label".

Rigol MSO5104 Specifications

General

Type	Tabletop
Product type	-
Bandwidth	100 MHz
Sampling rate	500000 MS/s
Channels quantity	16 channels
Minimum time base setting (per division)	3.5 ns
Display type	LCD
Display diagonal	9 \
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	75 W
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	367 mm
