Chapter 12 Reference Waveform RIGOL
MSO5000 User Guide 12-5
To Export to Internal or External Memory
You can also save the current reference waveform to the internal memory or external
USB storage device. The file format of the reference waveform is ".ref", ".bin", or
".csv".
Press More → Export to enter the reference waveform file saving interface. Please
refer to descriptions in "Store and Load" to save the reference waveform to the
internal or external memory. Only when the reference waveform is saved, can this
export function is valid.
Note: MSO5000 series oscilloscope only supports the flash memory USB storage
device of FAT32 format.
To Import from Internal or External Memory
You can also import the stored reference waveform file from the internal memory or
external USB storage device to the instrument and display the file on the screen.
Press More → Import to enter the reference waveform file loading interface. Please
refer to descriptions in "Store and Load" to import the reference waveform to the
instrument and display it on the screen.
Note: MSO5000 series oscilloscope only supports the flash memory USB storage
device of FAT32 format.

Rigol MSO5104 Specifications

General

Type	Tabletop
Product type	-
Bandwidth	100 MHz
Sampling rate	500000 MS/s
Channels quantity	16 channels
Minimum time base setting (per division)	3.5 ns
Display type	LCD
Display diagonal	9 \
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	75 W
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	367 mm
