Chapter 20 System Utility Function Setting RIGOL
MSO5000 User Guide 20-7
System-related
Beeper
When the beeper is enabled, you can hear the sound of the beeper when you
perform the following operations:
⚫ Press a key or a menu key on the front panel
⚫ Enable the touch screen
⚫ When a prompt message is displayed
Press Utility and then press Beeper continuously to select "ON" ( ) or "OFF" ( ).
By default, it is OFF.
Language
This oscilloscope supports menus in multiple languages. Both Chinese and English
are available for the display of the help information, prompt messages, and interface.
Press Utility → Language and rotate the multi-function knob to select the
desired language; then, press down the knob to select the language. You can
also press Language continuously to select the language or enable the touch screen
to tap the desired language and select it.
System Information
Press Utility → System → About to view the system information of the
oscilloscope, including the manufacturer, product model, serial number, etc.
Besides, you can also press About to view the system information of the oscilloscope
in the "Help" system menu.
Power On
You can set the system configuration to be recalled when the oscilloscope is powered
on again after power-off.
Press Utility → System, and then press Power On continuously to select "Last" or
"Default". By default, it is "Default".
⚫ Last: returns to the setting of the system at last power-off.
⚫ Default: returns to the factory setting of the system.

Rigol MSO5104 Specifications

General

Type	Tabletop
Product type	-
Bandwidth	100 MHz
Sampling rate	500000 MS/s
Channels quantity	16 channels
Minimum time base setting (per division)	3.5 ns
Display type	LCD
Display diagonal	9 \
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	75 W
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	367 mm
