RIGOL Chapter 17 Function/Arbitrary Waveform Generator (Option)
17-8 MSO5000 User Guide
Gauss
Press Wave, rotate the multifunction knob to select "Gauss". Press down the
knob to select it. You can also press Wave continuously or enable the touch screen
to select it. At this time, you can set the parameters for the Gauss waveform (as
shown in the figure below). For setting methods, refer to descriptions in "To Output
Sine".
Figure 17-7 Gauss
Lorentz
Press Wave, rotate the multifunction knob to select "Lorentz". Press down the
knob to select it. You can also press Wave continuously or enable the touch screen
to select it. At this time, you can set the parameters for the Lorentz waveform (as
shown in the figure below). For setting methods, refer to descriptions in "To Output
Sine".
Figure 17-8 Lorentz

Rigol MSO5104 Specifications

General

Type	Tabletop
Product type	-
Bandwidth	100 MHz
Sampling rate	500000 MS/s
Channels quantity	16 channels
Minimum time base setting (per division)	3.5 ns
Display type	LCD
Display diagonal	9 \
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	75 W
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	367 mm
