RIGOL Chapter 11 Protocol Decoding
11-38 MSO5000 User Guide
"Falling( )" as the desired clock edge.
⚫ Set the WS source and the threshold
➢ Press WS and rotate the multifunction knob to select the desired
channel, and then press down the knob to select it. You can also press
WS continuously or enable the touch screen to select it. The available
channels include CH1-CH4 and D0-D15.
➢ When you select the analog channel (CH1-CH4), press WS Thre below
WS, then rotate the multifunction knob or use the pop-up numeric
keypad to set the threshold of the WS signal. When you modify the WS
threshold, a dotted line displaying the current threshold level is
displayed on the screen. The dotted line disappears in about 2 s after
you stop modifying the threshold.
⚫ Set the data channel source and the threshold
➢ Press Data and rotate the multifunction knob to select the desired
data channel source, and then press down the knob to select it. You
can also press Data continuously or enable the touch screen to select
it. The available channels include CH1-CH4 and D0-D15.
➢ When you select the analog channel (CH1-CH4), press Data Thre
below Data, then rotate the multifunction knob or use the pop-up
numeric keypad to set the threshold of the data signal. When you
modify the threshold of the data signal, a dotted line displaying the
current threshold level is displayed on the screen. The dotted line
disappears in about 2 s after you stop modifying the threshold.
4. Bus Setting
Press Settings to enter the bus setting menu.
⚫ Set the word size
Press Word Size, then rotate the multifunction knob or use the
pop-up numeric keypad to set the word size. Its range is from 4 to 32.
⚫ Set the receiver word size
Press Receive, then rotate the multifunction knob or use the pop-up
numeric keypad to set the receiver word size. Its range is from 4 to 32.
⚫ Alignment
Press Alignment and rotate the multifunction knob to select the
alignment way for data signal. Then press down the knob to select it. You
can also press Alignment continuously or enable the touch screen to
select it. The available alignment ways include I2S, LJ, and RJ.

Rigol MSO5104 Specifications

General

Type	Tabletop
Product type	-
Bandwidth	100 MHz
Sampling rate	500000 MS/s
Channels quantity	16 channels
Minimum time base setting (per division)	3.5 ns
Display type	LCD
Display diagonal	9 \
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	75 W
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	367 mm
