Chapter 18 Store and Load RIGOL
MSO5000 User Guide 18-21
Offset
0 V
Scale
500 mV
ωc1
40 MHz
ωc2
80 MHz
Invert
OFF
Band Stop
Operation
OFF
Source
CH1
Offset
0 V
Scale
500 mV
ωc1
40 MHz
ωc2
80 MHz
Invert
OFF
AX+B
Operation
OFF
Source
CH1
Offset
0 V
Scale
500 mV
A
1
B
0
Invert
OFF
Logic Analyzer (LA)
Select
None
D7-D0
OFF
D15-D8
OFF
Wave Size
Medium
Arrange
D15-D0
Threshold
D7-D0
1.4 V
D15-D8
1.4 V
Label
Display
OFF
Select
D0
Label
D0
Protocol Decoding (Decode)
Bus Type
Parallel
Bus Status
OFF
Format
Hex
Label
ON
Event Table
OFF
Noise Reject
OFF
Clock
OFF
RS232
